Product Details
Place of Origin: USA
Brand Name: Hp e
Certification: ce
Model Number: JW633A
Payment & Shipping Terms
Minimum Order Quantity: 1 pc
Price: $10/pc
Packaging Details: original new
Delivery Time: 1-3 days
Payment Terms: T/T
Supply Ability: 500pcs
|
Part Number:
|
JW633A
|
Details:
|
Campus Network Switch
|
Keywords:
|
10G Uplink Switch
|
Product Features:
|
High-availability Access Switch
|
Packing:
|
Original
|
Shipping:
|
DHL FEDEX UPS
|
Payment:
|
TT 100% In Advance
|
Lead Time:
|
1-2 Days
|
|
Part Number:
|
JW633A
|
|
Details:
|
Campus Network Switch
|
|
Keywords:
|
10G Uplink Switch
|
|
Product Features:
|
High-availability Access Switch
|
|
Packing:
|
Original
|
|
Shipping:
|
DHL FEDEX UPS
|
|
Payment:
|
TT 100% In Advance
|
|
Lead Time:
|
1-2 Days
|
JW678A Dual-Band Indoor Access Point for Enterprises original new in stock
Product Brief
The JW678A is an Aruba AP-505 (RW) Unified Campus Access Point designed for medium-density enterprise deployments, offering Wi-Fi 6 (802.11ax) performance, integrated Bluetooth Low Energy (BLE), and advanced security features. It delivers high efficiency, optimized roaming, and strong wireless coverage for business environments.
Product Detail Table
| Specification | Description |
|---|---|
| Brand | Aruba |
| Model | JW678A |
| Product Name | Aruba AP-505 (RW) Unified Campus Access Point |
| Wireless Standard | IEEE 802.11ax (Wi-Fi 6) |
| Frequency Bands | 2.4 GHz and 5 GHz dual-band |
| Antenna Type | Internal, integrated antennas |
| MIMO | 2x2:2 |
| Max Data Rate | Up to 1.774 Gbps |
| Power Options | IEEE 802.3af/at PoE, DC power |
| Security | WPA3, Enhanced Open, WIDS/WIPS |
| Management | Aruba Central, AirWave, CLI, Web UI |
| Mounting Options | Wall, ceiling |
| Operating Temperature | 0°C to +50°C |
Key Features
Dual-radio Wi-Fi 6 design for enhanced performance and capacity
Integrated BLE for IoT and location-based services
Advanced security with WPA3 and intrusion protection
Smart power saving and energy-efficient operation
Seamless roaming and high user density support
Full Specifications Table
| Feature | Details |
|---|---|
| Wireless Technology | IEEE 802.11a/b/g/n/ac/ax |
| Radios | Dual (2.4 GHz, 5 GHz) |
| Spatial Streams | 2x2:2 MIMO |
| Channel Bandwidth | 20/40/80 MHz |
| Max Clients | 512+ per AP (recommended environment dependent) |
| Modulation | OFDMA, MU-MIMO |
| Ethernet Ports | 1 x 10/100/1000Base-T (PoE-enabled) |
| Power Consumption | Max 13.5W (PoE) |
| Dimensions | 200 mm x 200 mm x 45 mm |
| Weight | 650 g |
| Operating Humidity | 5% to 93% non-condensing |
| Certifications | CE, FCC, IC, RoHS |
Similar Models Specification Table
| Model | Wireless Standard | MIMO | Max Data Rate | PoE | BLE Support |
|---|---|---|---|---|---|
| JW678A | 802.11ax | 2x2:2 | 1.774 Gbps | Yes | Yes |
| JW679A | 802.11ax | 4x4:4 | 2.4 Gbps | Yes | Yes |
| JW680A | 802.11ax | 2x2:2 | 1.774 Gbps | Yes | Yes |
| JW681A | 802.11ax | 4x4:4 | 2.4 Gbps | Yes | Yes |
Latest Model in Same Series Table
| Model | Wireless Standard | MIMO | Max Data Rate | Extra Features |
|---|---|---|---|---|
| R8W01A | 802.11ax (Wi-Fi 6E) | 4x4:4 | 3.9 Gbps | 6 GHz tri-band, advanced IoT support |
Sinanova specializes in supplying ICT networking equipment from leading brands such as Cisco, Huawei, and Juniper. Our product range includes switches, routers, firewalls, wireless access points and controllers, IP phones, video conferencing solutions, and more. We are committed to delivering original and reliable hardware along with professional ICT solutions—all at competitive prices. Our high-quality service ensures a smooth and hassle-free purchasing experience for our clients.
