J9285D 1G SFP LX Transceiver for Long-Range SMF Connectivity
The HPE Aruba J9285D is a 1-Gigabit SFP LX transceiver module designed for long-distance single-mode fiber (SMF) connections. It supports data rates up to 1 Gbps and operates over distances up to 10 kilometers, making it ideal for enterprise access networks and core switching applications requiring long-range fiber optics.
| Attribute | Description |
|---|---|
| Brand | HPE Aruba |
| Part Number | J9285D |
| Product Type | SFP LX Transceiver Module |
| Data Rate | 1 Gbps |
| Interface | SFP (Small Form-Factor Pluggable) |
| Connector Type | LC Duplex |
| Wavelength | 1310 nm |
| Transmission Distance | Up to 10 km over single-mode fiber |
| Compatibility | Aruba and HPE switches and routers |
| DDM Support | Yes |
| Form Factor | Hot-swappable |
| Fiber Type | Single-Mode Fiber (SMF) |
| Operating Temperature | 0°C to 70°C |
1 Gbps long-range optical connectivity
LC duplex connector and 1310 nm wavelength
Supports up to 10 km over standard single-mode fiber
Interoperable with Aruba and HPE networking equipment
Hot-swappable and DDM enabled for monitoring and flexibility
Ideal for access layer, campus, or enterprise edge deployment
| Parameter | Value |
|---|---|
| Form Factor | SFP |
| Data Rate | 1 Gbps |
| Connector | LC Duplex |
| Cable Type | Single-Mode Fiber |
| Wavelength | 1310 nm |
| Max Distance | 10 km |
| Operating Temperature | 0°C to 70°C |
| DDM | Supported |
| Hot-Swappable | Yes |
| Model | Data Rate | Distance | Connector | Wavelength | Fiber Type | DDM |
|---|---|---|---|---|---|---|
| J9285D | 1 Gbps | 10 km | LC | 1310 nm | SMF | Yes |
| J4858D | 1 Gbps | 550 m | LC | 850 nm | MMF | Yes |
| J4859D | 1 Gbps | 10 km | LC | 1310 nm | SMF | Yes |
| J9151E | 10 Gbps | 10 km | LC | 1310 nm | SMF | Yes |
| Model | Data Rate | Distance | Connector | Fiber Type | Feature |
|---|---|---|---|---|---|
| J9150D | 10 Gbps | 300 m | LC | MMF | Short-range 10G module |
| J9151E | 10 Gbps | 10 km | LC | SMF | Long-range 10G SFP+ |
| J4859D | 1 Gbps | 10 km | LC | SMF | 1G alternative for J9285D |
| J9285D | 1 Gbps | 10 km | LC | SMF | Reliable 1G long-distance option |
